Craftex

Craftex CX103 bandsaw blade size

Metal-cutting bandsaw

Photo: Craftex · Source ↗︎
Craftex CX103

Click the photo to zoom in and move the pointer to look around. Esc closes.
Replacement blade lengthDocumented dimensions

93 in

Full blade loop length · 2362.2 mm

Blade width 0.75 in – 0.75 in

Find a replacement blade ↓
10 other machines take this exact blade ↗︎

Specification

As written by the manufacturer
Blade size: 3/4" x 0.032" x 93"
Blade loop length
2362.2 mm · 93 in
Blade width range
0.75 in – 0.75 in
Thickness constraint
0.032 in
Motor / supply
1 HP TEFC; 110V
Blade speeds
85, 130, 180 and 235 FPM
Cutting capacity at 90°
Rectangular 7" x 12"; round 7"
Documented for
Canada
Source checked
1 Oct 2026

Canadian source (Busy Bee Tools, owner of the Craftex brand), standard machine only. Blade length, width and thickness are as stated; TPI and blade material are not established by these dimensions. The user manual repeats the width and length but misprints the thickness as 0.32"; the product page value (0.032") is recorded. One replacement blade listed on the page is "93" X 3/4" X .035" (a bi-metal option), so check the thickness of your current blade. Check your model label before ordering.

Find a replacement blade

Search by the documented size, then check the product details against this page before ordering.

Australia · Change country

No retailer mapping for this configuration in your selected country yet. Use the documented size with a local supplier.

Retailer searches do not establish a product fit. Coverage is country-specific; shipping is not guaranteed. Affiliate disclosure: we may earn a commission from eligible links, at no cost to you. As an Amazon Associate I earn from qualifying purchases. A link does not indicate current stock or a price promise.

Workshop reports

Reports from visitors, not verified by BenchRefill. The size above comes from the manufacturer source.

No reports yet for this configuration.

We read every report before it appears. We remove spam and personal details but publish negative reports too. We cannot confirm that the writer owns this machine.

Fitted this size? Tell others how it went
How did it fit?

Your name, note and product are shown publicly after review. Privacy

Same blade, other machines

The 93 in blade is documented for 10 other machines.
