Illustration: Floor-standing bandsaw
Shop FoxBandsaw blade
W1706
US · standard configuration
Documented dimensionsBlade Length 92-1/2" to 93-1/2"; Blade Size Range 1/8" to 3/4"; supplied Saw Blade 6TPI x 3/8" x 93-1/2"View size →
Replacement blade lengthDocumented dimensions
131.5 in
Full blade loop length · 3340.1 mm
Blade width 0.125 in – 1 in
2 other machines take this exact blade ↗︎Specification
- As written by the manufacturer
- BLADE SIZE 131-1/2" x (1/8" - 1") x 0.025"
- Blade loop length
- 3340.1 mm · 131.5 in
- Blade width range
- 0.125 in – 1 in
- Thickness constraint
- Unknown — not documented here
- Motor / supply
- 220 V, 1 phase, 60 Hz
- Throat
- 16-1/4 in
- Cutting height
- 12 in
- Blade speed
- 540 - 3,600 SFPM (wood); 100 - 650 SFPM (metal)
- Documented for
- Canada
- Source checked
- 1 Oct 2026
Canadian source, standard machine only. This is a variable-speed wood/metal machine; its blade length (131-1/2 in) differs from the KC-1702FXB wood bandsaw, so do not mix the two. Blade length and the blade width range are taken from King Canada's blade size line. The 0.025 in figure in that line is the blade gauge, not a stated maximum thickness, so no thickness limit is recorded. TPI is not a machine limit. Check your model label before ordering.
Find a replacement blade
Search by the documented size, then check the product details against this page before ordering.
No retailer mapping for this configuration in your selected country yet. Use the documented size with a local supplier.
Retailer searches do not establish a product fit. Coverage is country-specific; shipping is not guaranteed. Affiliate disclosure: we may earn a commission from eligible links, at no cost to you. As an Amazon Associate I earn from qualifying purchases. A link does not indicate current stock or a price promise.
Same blade, other machines
The 131-1/2 in blade is documented for 2 other machines.
