Illustration: Floor-standing bandsaw
FelderBandsaw blade
FB 610
US · standard configuration
Documented dimensionsBlade length in inches 179; Blade width in inches ¼–1⅛View size →
Replacement blade lengthDocumented dimensions
152.125 in
Full blade loop length · 3863.98 mm
Blade width 0.125 in – 1.25 in
Specification
- As written by the manufacturer
- BLADE SIZE 152-1/8" x (1/8" - 1-1/4") x 0.025"
- Blade loop length
- 3863.975 mm · 152.125 in
- Blade width range
- 0.125 in – 1.25 in
- Thickness constraint
- Unknown — not documented here
- Motor / supply
- 16 A / 8 A; 110 V / 220 V, 1 phase, 60 Hz (prewired 220 V)
- Throat
- 20-1/4 in
- Cutting height
- 12 in
- Documented for
- Canada
- Source checked
- 1 Oct 2026
Canadian source, standard machine only. Blade length and the blade width range are taken from King Canada's blade size line; the manual's optional blade table lists the same 152-1/8 in length. The 0.025 in figure in that line is the blade gauge (wider optional blades are 0.032 in), not a stated maximum thickness, so no thickness limit is recorded. TPI is not a machine limit. Check your model label before ordering.
Find a replacement blade
Search by the documented size, then check the product details against this page before ordering.
No retailer mapping for this configuration in your selected country yet. Use the documented size with a local supplier.
Retailer searches do not establish a product fit. Coverage is country-specific; shipping is not guaranteed. Affiliate disclosure: we may earn a commission from eligible links, at no cost to you. As an Amazon Associate I earn from qualifying purchases. A link does not indicate current stock or a price promise.
Similar machines from other brands
Understanding dimensions ↗︎
Photo: RIKON
RIKONBandsaw blade
10-342
US · standard configuration
Documented dimensions153 in loop; 0.25–1.375 in widthView size →
Photo: Laguna Tools
Laguna ToolsBandsaw blade
LT24x24
US · standard configuration
Documented dimensionsBlade Length: 201″; Minimum Blade Width: *⅛″ (*with optional Cool Blocks) or ¼″ standard; Maximum Blade Width: 1-½″View size →
