Photo: Grizzly
GrizzlyBandsaw blade
G9743
US · standard configuration
Documented dimensionsStd. Blade Length 104-1/2 in.; Std. Blade Width 1 in.View size →
Replacement blade lengthDocumented dimensions
131.75 in
Full blade loop length · 3346.45 mm
Blade width 1 in – 1 in
1 other machine takes this exact blade ↗︎Specification
- As written by the manufacturer
- BLADE 131-3/4" x 1" x 0.032"
- Blade loop length
- 3346.45 mm · 131.75 in
- Blade width range
- 1 in – 1 in
- Thickness constraint
- 0.032 in
- Motor / supply
- 2 HP, 2.5 Amp.; 600V, 3 phase, 60 Hz
- Blade speed
- 80-250 FPM (variable)
- Cutting capacity at 90°
- Rect. 9" x 18"; Diam. 9"
- Documented for
- Canada
- Source checked
- 1 Oct 2026
Canadian source, standard machine only. Blade length, width and thickness are as stated; TPI and blade material are not established by these dimensions. King's replacement blades listed on the same page are 131-3/4" x .032" x 1". Check your model label before ordering.
Find a replacement blade
Search by the documented size, then check the product details against this page before ordering.
No retailer mapping for this configuration in your selected country yet. Use the documented size with a local supplier.
Retailer searches do not establish a product fit. Coverage is country-specific; shipping is not guaranteed. Affiliate disclosure: we may earn a commission from eligible links, at no cost to you. As an Amazon Associate I earn from qualifying purchases. A link does not indicate current stock or a price promise.
Same blade, other machines
The 131-3/4 in blade is documented for 1 other machine.
