Scheppach

Scheppach MBS1100 bandsaw blade size

Portable bandsaw · Also listed as 5901507901, 5901507904

Photo: Scheppach · Source ↗︎
Scheppach MBS1100

Click the photo to zoom in and move the pointer to look around. Esc closes.
Replacement blade lengthDocumented dimensions

1140 mm

Full blade loop length · 44.88 in

Blade width 12.7 mm – 12.7 mm

Find a replacement blade ↓
13 other machines take this exact blade ↗︎

Specification

As written by the manufacturer
Sägeband Länge 1140 mm; max. Sägeband Breite 12.7 mm; Sägeband Stärke max. 0.65 mm
Blade loop length
1140 mm · 44.8819 in
Blade width range
12.7 mm – 12.7 mm
Thickness constraint
0.65 mm
Article number
5901507904 (also 5901507901)
Motor / supply
1100 W (S1), mains
Blade speed
0.7 – 2.4 m/s
Cutting width (freehand)
127 mm
Documented for
Germany
Source checked
30 Sep 2026

German source, standard machine only. Blade length, width and thickness are as stated; TPI and blade material are not established by these dimensions. The description on the same page gives the blades as 1140 mm long and 12,7 mm wide; article 5901507901 lists the same values. Check your model label before ordering.

Find a replacement blade

Search by the documented size, then check the product details against this page before ordering.

Canada · Change country

No retailer mapping for this configuration in your selected country yet. Use the documented size with a local supplier.

Retailer searches do not establish a product fit. Coverage is country-specific; shipping is not guaranteed. Affiliate disclosure: we may earn a commission from eligible links, at no cost to you. As an Amazon Associate I earn from qualifying purchases. A link does not indicate current stock or a price promise.

Workshop reports

Reports from visitors, not verified by BenchRefill. The size above comes from the manufacturer source.

No reports yet for this configuration.

We read every report before it appears. We remove spam and personal details but publish negative reports too. We cannot confirm that the writer owns this machine.

Fitted this size? Tell others how it went
How did it fit?

Your name, note and product are shown publicly after review. Privacy

Same blade, other machines

The 1140 mm blade is documented for 13 other machines.

All 1140 mm machines ↗︎

Similar machines from other brands

Understanding dimensions ↗︎
DEWALT DCS378

Photo: DEWALT
DEWALTBandsaw blade

DCS378

CA · standard configuration

Documented dimensions
0.02" (0.5 mm) thick, 1/2" (12.7 mm) wide and 35-1/4"–35-3/8" (896 mm–899 mm) long blades; product page: "Saw uses 35 3/8 in. blade (900mm)"View size →
