Size search: 1140 mm portable band saw blade
DEWALT DCS374 bandsaw blade size
Portable bandsaw · Also listed as DCS374B, DCS374N, DCS374N-XJ, DCS374P2
Replacement blade lengthDocumented dimensions
1140 mm
Full blade loop length · 44.88 in
Blade width 12.5 mm – 12.5 mm
13 other machines take this exact blade ↗︎Specification
- As written by the manufacturer
- Blade length dimensions mm 1140; Blade width dimensions mm 0.5; Blade height dimensions mm 12.5
- Blade loop length
- 1140 mm · 44.8819 in
- Blade width range
- 12.5 mm – 12.5 mm
- Thickness constraint
- 0.5 mm
- Motor / supply
- 18 VDC XR Li-Ion
- Max. cutting capacity
- 127 mm
- No-load speed
- 0–150 m/min
- Documented for
- United Kingdom
- Source checked
- 29 Sep 2026
UK/EU Type 1 manual from the DeWALT UK service site; DEWALT labels band width as 'height' (12.5 mm) and thickness as 'width' (0.5 mm). TPI is not established by these dimensions.
Find a replacement blade
Search by the documented size, then check the product details against this page before ordering.
Retailer searches do not establish a product fit. Coverage is country-specific; shipping is not guaranteed. Affiliate disclosure: we may earn a commission from eligible links, at no cost to you. As an Amazon Associate I earn from qualifying purchases. A link does not indicate current stock or a price promise.
Fitted this size? Tell others how it went
Reports from visitors, not verified by BenchRefill. The size above comes from the manufacturer source.
We read every report before it appears. We remove spam and personal details but publish negative reports too. We cannot confirm that the writer owns this machine.
Same blade, other machines
The 1140 mm blade is documented for 13 other machines.
Güde MBS 1100Portable bandsaw · DE
HiKOKI CB3612DAPortable bandsaw · UK
Makita 2107FPortable bandsaw · US
Makita DPB180Portable bandsaw · UK
Makita GBP01Portable bandsaw · US
Makita PB002GPortable bandsaw · UK
Makita XBP02Portable bandsaw · US- Milwaukee M18 FBS125Portable bandsaw · AU
- Milwaukee M18 FBS125DOPortable bandsaw · AU
Optimum SQ-V10Portable bandsaw · DE
Scheppach MBS1100Portable bandsaw · DE
Scheppach MBS1200xtPortable bandsaw · DE
More from DEWALT
All DEWALT machines ↗︎
Photo: DEWALT
DEWALTBandsaw blade
DCS371
UK · standard configuration
Documented dimensionsBlade dimensions mm 835 x 12 x 0.5View size →
Photo: DEWALT
DEWALTBandsaw blade
DCS378
UK · standard configuration
Documented dimensionsBlade length dimensions mm 899; Blade width dimensions mm 0.5; Blade height dimensions mm 12.7View size →
Photo: DEWALT
DEWALTSanding belt
DCW220
UK · standard configuration
Documented dimensions75mm x 533mmView size →
Similar machines from other brands
Understanding dimensions ↗︎
Photo: Milwaukee
MilwaukeeBandsaw blade
M12 FBS64
UK · standard configuration
Documented dimensionsBlade length 776.3 mmView size →
Photo: HiKOKI
HiKOKIBandsaw blade
CB3612DA
UK · standard configuration
Documented dimensionsBand saw blade length 1140 mm; Band saw blade width 12.5 mm; Band saw blade thickness 0.5 mmView size →
Photo: Milwaukee
MilwaukeeBandsaw blade
M18 FBS127DO
UK · standard configuration
Documented dimensionsBlade length 1,139.8 mmView size →
